Revised instrument cluster for 2003
#1
Registered User
Thread Starter
Join Date: Nov 2000
Location: Tracy
Posts: 821
Likes: 0
Received 0 Likes
on
0 Posts
With the recent discussion on what changes we'd like to see for 2003 (2003 Wish List), I had commented on some changes that I'd like to see on the instrument cluster/gauge package. Here's a visual representation of what I meant. I found a photo of the gauge cluster on Temple of VTEC and started with that.
Here's the original:
And here's my idea:
The second photo includes the following changes:
1) moved the "x1000r/min" label next to the "10" on the tach
2) moved all of the idiot lights to a single area
3) moved the fuel gauge to the left under the water temp gauge
4) added an oil temp gauge where the fuel gauge used to be
5) added an oil pressure gauge under the oil temp gauge
6) moved the "pictographs" for each gauge to the outside for better visibility
7) changed all bar graphs to use smaller segments for better accuracy
I also just noticed that the fuel gauge shouldn't have a red area near the "full" mark. My bad.
The oil pressure gauge should also include a red area for low pressure readings.
Here's the original:
And here's my idea:
The second photo includes the following changes:
1) moved the "x1000r/min" label next to the "10" on the tach
2) moved all of the idiot lights to a single area
3) moved the fuel gauge to the left under the water temp gauge
4) added an oil temp gauge where the fuel gauge used to be
5) added an oil pressure gauge under the oil temp gauge
6) moved the "pictographs" for each gauge to the outside for better visibility
7) changed all bar graphs to use smaller segments for better accuracy
I also just noticed that the fuel gauge shouldn't have a red area near the "full" mark. My bad.
The oil pressure gauge should also include a red area for low pressure readings.
#7
Registered User
Join Date: Nov 2001
Location: socal
Posts: 6,006
Likes: 0
Received 0 Likes
on
0 Posts
i like the idea of giving more info (oil temp and pressure gauages) to the driver ...
but do we need 10k rpm on the cluster when our engine is not suppose to rev that high?
but do we need 10k rpm on the cluster when our engine is not suppose to rev that high?
Trending Topics
#8
Registered User
Thread Starter
Join Date: Nov 2000
Location: Tracy
Posts: 821
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by stockae92
i like the idea of giving more info (oil temp and pressure gauages) to the driver ...
but do we need 10k rpm on the cluster when our engine is not suppose to rev that high?
i like the idea of giving more info (oil temp and pressure gauages) to the driver ...
but do we need 10k rpm on the cluster when our engine is not suppose to rev that high?
Originally posted by SkipX
I would prefer LED digits instead of bars. It is about precision?
I would prefer LED digits instead of bars. It is about precision?
