Smoke on takeoff

Thread Tools

Old Nov 11, 2021 | 02:07 PM
  #21
B serious's Avatar
Member (Premium)
15 Year Member
Liked
Loved
Community Favorite

Joined: Nov 2007
Posts: 8,841
Likes: 1,705
From: Illnoise. WAY downtown, jerky.
Default

Originally Posted by Orjinal
PCV set up is an 04-05 valve cover with the 04-05 OEM PCV. Hose routing is OEM. There is no catch can. And yes, the car for the most part only sees short drives. There is no misfire code at the moment but I'll look into replacing the spark plugs soon before it becomes an issue.

Would vacuum caused by decelerating with the car in gear cause the oil to be sucked into the intake manifold?
Vacuum caused by decel would pull oil in from the PCV or breather. It does so as part of normal operation. However, the amount is virtually nothing.

If it pulls in more than virtually nothing...then...you get smoke.

If there's a situation in which liquid oil exists at the breather or PCV port...then...yep. Smoke.

Check your compression. Hopefully not..but maybe you dropped something into one of the cylinders when you did that plug swap and it caused some scratches.

Best case scenario is that you just have some sort of breather issue.

Valve seals aren't a huge deal. It would be a day's job. But not that much stuff has to come apart.

Last edited by B serious; Nov 11, 2021 at 02:10 PM.
Reply
Old Nov 11, 2021 | 04:15 PM
  #22
windhund116's Avatar
Gold Member (Premium)
10 Year Member
Liked
Loved
Community Favorite

Joined: Sep 2014
Posts: 11,361
Likes: 1,795
Default

Originally Posted by B serious
Vacuum caused by decel would pull oil in from the PCV or breather. It does so as part of normal operation. However, the amount is virtually nothing.

If it pulls in more than virtually nothing...then...you get smoke.

If there's a situation in which liquid oil exists at the breather or PCV port...then...yep. Smoke.

Check your compression. Hopefully not..but maybe you dropped something into one of the cylinders when you did that plug swap and it caused some scratches.

Best case scenario is that you just have some sort of breather issue.

Valve seals aren't a huge deal. It would be a day's job. But not that much stuff has to come apart.
Smoke right after a hard deceleration is most likely valve stem seals. But, the OP's car is showing smoking at idle. Or right off idle.

I'm still not convinced that all four plugs are oil fouled.
Reply
Old Nov 11, 2021 | 05:41 PM
  #23
B serious's Avatar
Member (Premium)
15 Year Member
Liked
Loved
Community Favorite

Joined: Nov 2007
Posts: 8,841
Likes: 1,705
From: Illnoise. WAY downtown, jerky.
Default

If my AP2 sits at idle for more than like...5 mins, it will start billowing an alarming amount of smoke.

It burns almost no oil during regular or track use.

But I get a ton of crankcase blowby in the valve cover. This car's primary purpose is for the track...which kinda necessitates catch cans. I had to use a lot of cunning and recirculate the cans...or I would die inside the cabin from fumes.

The entire situation is inexplicable. So...I've just gone on with my life and let the car live its life.

This doesn't help the OP. But it sure makes me feel better.
Reply
Old Nov 11, 2021 | 09:23 PM
  #24
ApexHunter's Avatar
15 Year Member
Liked
Loved
Community Favorite

Joined: Nov 2008
Posts: 199
Likes: 34
From: Seattle area
Default

^Sounds like my car. Doesn't burn much oil if any during a track day. No smoke after normal periods of idle or engine braking. But if it idles for an extended period of time, smoke cloud. Scared the hell out of me the first time.
It's an ap1 engine with 2006-09 valve cover and PCV. Breather to intake arm, no catch cans yet but on the list. Totally stock longblock, runs great, makes all the power it should, has about 120k miles.

Originally Posted by windhund116
Smoke right after a hard deceleration is most likely valve stem seals. But, the OP's car is showing smoking at idle. Or right off idle.
Still true right off idle. Sure, it will pull more vacuum during engine braking.... and at idle throttle is still closed and intake stroke is going to pull air through path of least resistance. Engine is still pulling a lot of vaccum unless you have huge cams, big vacuum leak etc.

Last edited by ApexHunter; Nov 11, 2021 at 09:26 PM.
Reply
Old Nov 12, 2021 | 02:16 AM
  #25
windhund116's Avatar
Gold Member (Premium)
10 Year Member
Liked
Loved
Community Favorite

Joined: Sep 2014
Posts: 11,361
Likes: 1,795
Default

Originally Posted by ApexHunter
Still true right off idle. Sure, it will pull more vacuum during engine braking.... and at idle throttle is still closed and intake stroke is going to pull air through path of least resistance. Engine is still pulling a lot of vacuum unless you have huge cams, big vacuum leak etc.
I had this old BMW 2002Ti that needed top end work. I would be coming down one of those steep inclines out of Lake Tahoe. No problems going in 2nd or 3rd down the hill. BUT at the bottom, when I gunned it --- looked like this. I'd tell my passengers I was setting a screen to hide from rice rockets.



Reply
Old Nov 12, 2021 | 05:06 AM
  #26
engifineer's Avatar
Moderator
10 Year Member
Community Builder
Liked
Loved

Joined: May 2014
Posts: 7,907
Likes: 2,480
Default

Hmmm the whole smoking at idle people are seeing is interesting. I could let mine idle all day like a truck driver taking a nap and never see any smoke. But of course have seen it on some autox runs and track before installing a catch can.
Reply
Old Nov 12, 2021 | 08:20 AM
  #27
sdosmil77's Avatar
Gold Member (Premium)
15 Year Member
Photogenic
Photoriffic

Joined: Jun 2009
Posts: 1,703
Likes: 34
From: PA
Default


MINE WHEN IT HAD BAD RINGS DID THIS 24/7. THOUGHT I WAS SPYHUNTER, LOL
Reply
Old Nov 12, 2021 | 08:23 AM
  #28
engifineer's Avatar
Moderator
10 Year Member
Community Builder
Liked
Loved

Joined: May 2014
Posts: 7,907
Likes: 2,480
Default

^That looked like mine at an autocross event when I forgot to empty the catch can after a previous event and a track night event That can was full to the brim and people working course thought my motor was about to go lol
Reply
Old Nov 12, 2021 | 08:36 AM
  #29
Orjinal's Avatar
Thread Starter
Member (Premium)
Photogenic
Photoriffic
Liked
Loved

Joined: Jul 2011
Posts: 2,789
Likes: 181
From: Long Island, NY
Default

Oil sample was taken and will be sent out to Blackstone labs. I have another reading from back in 2019 to compare to. That'll provide an explanation if there is increased wear material in the oil.

As a side note, these odd issues is what kept me interested in this platform for over a decade.
Reply
Old Nov 12, 2021 | 09:08 AM
  #30
ApexHunter's Avatar
15 Year Member
Liked
Loved
Community Favorite

Joined: Nov 2008
Posts: 199
Likes: 34
From: Seattle area
Default

Subscribed. Let us know what you find!
Reply
